Triple Action Baler

POWER HYDROTECH is the leading manufacturer and exporter of Triple Action Baler in India. Our manufactured Triple action Baling Press are Demanding Product in the market for their high performance and low maintenance.

Suitable of Application for Triple Action Baler

Our baling press machine suitable for, stainless steel, copper aluminium scrap and a wide variety of materials such as steel cans, aluminium cans, wire, white goods, tubing, metal sheets, skeletons, aluminium coil scrap, aluminium tense scrap, alloy steel scrap, steel metal scrap, LMS scrap, CRC scrap, cast iron scrap, ferrous scrap, etc

Lowest operating costs
increased output and denser bales
Faster movement rates
Timings are shortened when high- and low-pressure pumps are used.
Low energy consumption
Installation is quite easy
Machine available in auto- plc control Operate Systems and semiautomatic hand lever Operate
Hydraulic systems that are extremely efficient
Lubrication system to reduce wear and tear to a minimum
An online chiller keeps the hydraulic fluid cold so the machine may function for longer periods of time.
Check Valves are included to prevent any accidents.
Wear-resistant plates that can be replaced
For shear large waste materials, shear blades on the edges of the top and internal container are provided.
Charge box with a large capacity
Three Type of models are available topside ejection, turn out ejection and side ejection

Model Specifications of Triple Action Baler

Model	PW 800	PW 1000	PW 1200
Pressure	100 TON	100 TON	100 TON
Chamber size	22 x 24 x 50	22 x 24 x 50	22 x 24 x 50
Bale size	8 x 8	10 x 10	12 x 12
Bale weight	20 to 25 KG	25 to 30 KG	30 to 35 KG
Operation	Hand Lever / Panel	Hand Lever / Panel	Hand Lever / Panel
Oil tank	800 L	800 L	800 L
Power	20 HP	20 HP	25 HP

Model	PW 1400	PW 1500	PW 1600	PW 1800
Pressure	120 TON	120 TON	120 TON	150 TON
Chamber size	30 x 25 x 60	30 x 25 x 60	36 x 30 x 60	40 x 30 x 72
Bale size	14 x 14	15 x 15	16 x 16	18 x 18
Bale weight	50 to 75 KG	50 to 80 KG	60 to 80 KG	80 to 120 KG
Operation	Hand Lever / Panel	Hand Lever / Panel	Hand Lever / Panel	Hand Lever / Panel
Oil tank	1000 L	1000 L	1200 L	1400 L
Power	30 HP	30 HP	40 HP	40 HP

Optional Features :

Feeding Hopper or Conveyor
PLC Operation System
Models available in Side Eject, Front Eject, Auto-Turnout
Oil Cooling

They are only for illustration purposes and are subject to modify in accordance with the customer's requirements and technological improvements.
Specifications are merely guidelines and may vary in response to client needs and technological improvements.
All stated weights, dimensions, and cycle times are merely estimating.
The type of scrap material the feeding rate, and the operator's skills all affect output.
